20-COMM-C | Allen Bradley | PowerFlex ControlNet Adapters

Description

• Manufacturer: Allen-Bradley
• Product No.: 20-COMM-C
• Product Type: PowerFlex ControlNet Adapters

Specifications

• Network Protocol: ControlNet
• Data Rate: 5 Mbps (fixed)
• Connection Limits:
  • 20 simultaneous CIP messaging connections
  • Unlimited input-only I/O connections
  • Types of connections:
    • 1 exclusive-owner I/O connection
    • Up to 3 redundant-owner I/O connections
    • 1 listen-only I/O connection
• Packet Rate: Up to 400 total I/O packets per second (200 in and 200 out)
• Power Consumption: 275 mA at 5 V DC supplied by the host (drive or DPI External Comms Kit)
• Relative Humidity: 5…95% non-condensing
• Storage Temperature: -40…85 °C (-40…185 °F)
• Operating Temperature: -10…50 °C (14…122 °F)
• Dimensions (LxWxH), approx: 10.3 cm x 8 cm x 1.6 cm
• Weight (Device): 0.5 kg
• Dimensional Weight: 1.5 kg
• Shipping Weight: 2.5 kg
