3300/45-02-01-03-00 Bently Nevada Proximity Transducer

Description

The Bently Nevada 3300/45-02-01-03-00 is an advanced eddy current proximity transducer system designed for precise vibration and position measurements on fluid-film bearing machines. It provides an output voltage directly proportional to the distance between the probe tip and the observed conductive surface.

Features

• High Sensitivity: Capable of detecting minute vibrations and positional changes.
• Backward Compatibility: Interchangeable with other 3300 series components.
• RFI/EMI Immunity: Improved resistance to radio frequency interference.
• SpringLoc Terminal Strips: Facilitates faster and more robust field wiring connections.
• Compliance: Meets the American Petroleum Institute’s (API) 670 Standard (4th Edition).

Technical Specifications

• Full-Scale Range: 0-10 mils pp
• Transducer Input: 3300 or 7200 Proximitor, 200 mV/mil
• Alarm Relay: Hermetically-Sealed
• Temperature Stability: Operates between 0°C and +45°C (32°F to 113°F)
• Power Supply: -24 Vdc
• Load: 10 kΩ
• Probe Gap: 1.0 mm (40 mils)
