Allen Bradley 1771-OFE2 PLC-5 Analog Output Module

Description

The Allen-Bradley 1771-IBD is a digital input module from the 1771 series, designed for use with the 1771 I/O chassis. It offers robust digital input capabilities for industrial automation systems.

Features

• Compatibility: Works with all 1771 I/O chassis except models 1771-A1, -A2, and -A42.
• Wiring Arm Screw Torque: 7-9 inch-pounds.

Specifications

• Backplane Current at 24 V DC: 130 mA @ 5 V DC ±5%.
• Thermal Dissipation:
  • Maximum: 24.7 BTU/hr.
  • Minimum: 3.4 BTU/hr.
• Power Dissipation:
  • Maximum: 7.3 Watts.
  • Minimum: 1.0 Watt.
• Minimum Input Current:
  • 4.5 mA at 10 V DC.
  • 15 mA at 30 V DC.
• Minimum Off-state Current: 2.0 mA @ 5 V DC.
• Maximum Off-state Voltage: 5 V DC.
• Minimum On-state Voltage: 10 V DC.
• Input Impedance: 2.2 kΩ maximum.
