CC-PDIL01 | Honeywell | Digital Input Module

Specifications

• Input Channels: 32
• Galvanic Isolation (any input terminal voltage referenced to common): 1500 VAC RMS or ±1500 VDC
• Isolation Technique: Optical (in IOM)
• DI Power Voltage Range: 18 to 30 VDC
• ON Sense Voltage/Current: 13 VDC (min) or 3 mA (min)
• OFF Sense Voltage/Current: 5 VDC (max) or 1.2 mA (max)
• Input Impedance: 4.2 KΩ
• Absolute Delay Across Input Filter and Isolation: 5 ms ± 20%
• Field Resistance for Guaranteed ON Condition: 300 Ω max @ 15 VDC
• Field Resistance for Guaranteed OFF Condition: 30 KΩ min @ 30 VDC

Features

• Extensive internal diagnostics for data integrity
• Open wire detection
• Optional redundancy
• Internal or external field power selection
• Onboard excitation power (no need for marshalling power)
• Supplies non-incendive field power
• Direct/reverse input indication
• Galvanic isolation
