CP6607 | ABB CP600-Pro Control Panel

Overview

The ABB CP6607 is a 7-inch control panel featuring a TFT graphical display and multi-touch screen. It is designed for PB610 applications and enables visualization of the AC500 V3 web server, offering a high-quality interface for industrial automation.

Technical Specifications

• Part Number: 1SAP560710R0001
• Display Size: 7 inches
• Resolution: 800 x 480 pixels
• Type: TFT-LCD
• Number of Colors: 16 million
• Brightness: 500 cd/m²
• Backlight: LED, typical lifetime of 40,000 hours at 25°C
• Touch Screen: Multi-touch, 2-point gestures, capacitive (PCAP), real glass, black passepartout

System Resources

• Processor: ARM Cortex-A9 dual-core, 800 MHz
• Operating System: Linux RT
• Memory:
  • Application Memory: Up to 240 MB for HMI projects
  • RAM: 1 GB
  • Flash: 4 GB
• Card Slot: SD card
• Data Backup:
  • Battery: 3V, 50 mAh, Lithium (rechargeable, not user-replaceable)
  • Data Buffering Time: Approx. 3 months at 25°C
  • Real-Time Clock Accuracy: < 100 ppm at 25°C
  • Battery Backup for RTC: Yes
