Discrete Output Module 1756-OW16I Allen-Bradley

Description

The 1756-OW16I Discrete Output Module from Allen-Bradley is a digital DC sourcing output module designed for the ControlLogix series. It provides 16 individually isolated channels for flexible control and integration into industrial automation systems.

Key Features

• Module Type: Digital DC Sourcing Output

• Number of Outputs: 16, individually isolated channels

• Contact Form: Normally Open (N.O.)

• Output Signal Delay:

• OFF to ON: 10 ms max

• ON to OFF: 10 ms max

• Enclosure Type: None (open-style)

• Removable Terminal Block: 1756-TBCH, 1756-TBS6H

Electrical Specifications

• Operating Voltage Range: 5–125V DC; 10–240V AC

• Output Voltage Range:

• 1 A @ 5–30V DC

• 0.5 A @ 48V DC

• 0.22 A @ 125V DC

• 1.5 A @ 120V AC (50/60 Hz)

• 0.75 A @ 240V AC (50/60 Hz)

• Current Draw @ 5.1V: 150 mA

• Total Backplane Power: 4.4 W

• Backplane Current (24V DC): 2 mA

• Power Dissipation: 4.5 W @ 60°C (140°F)

Output Characteristics

• Output Current:

• 2 A @ 5–30V DC

• 0.5 A @ 48V DC

• 0.25 A @ 125V DC

• 1.5 A @ 120V AC (50/60 Hz)

• 0.75 A @ 240V AC (50/60 Hz)

Environmental Conditions

• Operating Temperature Range: -40°C to +60°C (-40°F to +140°F)
