DS200SLCCG1ACC | General Electric | LAN Communication Card

Overview

The DS200SLCCG1ACC LAN Communication Card, manufactured by General Electric, is designed for the Mark V Turbine Control System Series. This card is essential for facilitating LAN communications within various drives and exciters in the GE family, supporting applications in wind, steam, and gas turbine automated systems.

Features

• Manufacturer: General Electric (GE)
• Product Series: Mark V
• Functional Description: LAN Communication Card

Hardware Specifications

Communication Capabilities

• Network Support:
  • DLAN and ARCNET network connections.
  • Isolated and nonisolated communications circuits.

Processing Components

• LAN Control Processor (LCP):
  • Central processing point for the board.
  • Program memory stored in two onboard EPROM memory modules.
• Dual Ported RAM:
  • Used for communication between the LCP and the drive control board.

User Interface

• Keypad:
  • Equipped with an attachable alphanumeric keypad.
  • Features a 16-position display for accessing system control settings and diagnostics.

Voltage Management

• Voltage Suppression:
  • Incorporates standardized voltage-suppressing components, including:
    • Capacitors
    • Resistors
    • Transistors
    • Integrated circuits

Safety and Installation

• Static Protection:
  • All drive boards are shipped in static-resistant plastic bags.
• Installation Guidelines:
  • Follow storage and installation parameters before beginning installation.
  • Only trained personnel should handle the card.
