DS200SLCCG3AFG | GE Fanuc | LAN Communication Card

Overview

The DS200SLCCG3AFG LAN Communication Card, manufactured by General Electric, is designed for use in the Mark V Series of turbine control systems. This card facilitates local area network (LAN) communication and is essential for various drives across the GE brand.

Features

• Manufacturer: GE General Electric
• Series: Mark V
• Part Number: DS200SLCCG3AFG
• Functional Description: LAN Communications Card

Hardware Specifications

Model Description

• Type: LAN Communication Board
• Functionality: Provides necessary space for interfacing with available LAN network connections.

Assembly and Interface

• LAN Control Processor (LCP): Filters signals sent to the board, enabling communication.
• Memory Storage: Features two attachable EPROM memory cartridges for program storage.
• Communication: Supports both isolated and nonisolated circuits for communication signals.
• Keypad Programmer: Includes an attachable alphanumeric keypad for easy access to system diagnostics and controls.
• Interfacing: Allows data exchange with the host drive’s control board using dual-ported RAM.

Protection Features

• The board incorporates voltage-limiting and suppression components such as rectifiers, diodes, and capacitors.
• The DS200SLCCG3AFG features both functional and artwork revisions, improving basic performance and adjusting the positioning of hardware elements.
