DS200TBCBG1AAA | GE Fanuc | RTD Input Termination Module

Overview

The DS200TBCBG1AAA is a 4-20 mA RTD Input Termination Module from General Electric, designed for the Mark V series in GE Speedtronic Control Systems. It facilitates precise temperature measurement through RTD sensors, providing reliable signal handling for industrial automation.

Features

• Input Signal: 4-20 mA, compatible with standard sensor data transmission.
• RTD Support: Compatible with PT100, PT1000, and other RTD sensors.
• Signal Handling: Accurate signal termination and conditioning for reliable readings.
• Configurable Inputs: Hardware jumpers enable 0-1 mA signal configuration.
• Output: Converts RTD signals into standardized analog or digital formats.

Power & Interface

• Power: Requires +5 V DC, 6 A.
• Interface: Includes terminal blocks and connectors for easy wiring of RTD sensors.
• Signal Output: Provides output signals compatible with industrial control systems.

Accuracy

Ensures precise temperature measurements by accurately correlating RTD resistance with temperature changes, essential for industrial applications.

Isolation & Safety

Incorporates isolation features to protect equipment from electrical interference and ensures safety in industrial environments.

Configuration

Offers flexible configuration and calibration options to adapt to various RTD sensor types and environmental conditions.

System Compatibility

Seamlessly integrates with multiple industrial control systems, ensuring smooth operation and control in automation setups.
