DX522 ABB Digital Input/Output Module
Manufacturer: ABB
-
Part Number: DX522
Condition：New with Original Package
Product Type: Digital Input/Output Module
-
Country of Origin: Sweden
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
General Information
- Extended Product Type: DX522
- Product ID: 1SAP245200R0001
- ABB Type Designation: DX522
- EAN: 4016779649186
- Catalog Description: Digital input/output module. 8 DI: 24VDC. 8 DO relay: 230VAC 3A (DX522)
- Long Description: DX522: S500 Digital input/output module. 8 DI: 24VDC. 8 DO relay: 230VAC 3A. 2..3 wire.
Ordering
- CN8: 85389091
- Invoice Description: Digital input/output module. 8 DI: 24VDC. 8 DO relay: 230VAC 3A (DX522)
- Made To Order: No
- Minimum Order Quantity: 1 piece
- Order Multiple: 1 piece
- Selling Unit of Measure: piece
Dimensions
- Product Net Weight: 0.177 kg
- Product Net Depth / Length: 62 mm
- Product Net Height: 76 mm
- Product Net Width: 67.5 mm
Technical
- Function: 8 DI: 24VDC. 8 DO relay: 230VAC 3A
- Number of Digital Inputs: 8
- Number of Digital Outputs: 8
- Number of Digital Configurable I/Os: 0
- Input Voltage Type: DC
- Input Current: 5 mA
- Maximum Input Voltage: 0 ... 30 V
- Delay Time (τ): 0.1 … 32 ms
- Output: Relay
- Output Voltage Type: AC
- Output Current: 3 A
- Output Voltage Maximum: 195.5 … 276 V
- Degree of Protection: IP20
- Supply Voltage: 20.4 … 28.8 V DC
Additional Information
- Product Main Type: DX522
- Product Name: Distributed Automation I/Os
