GE DS200TCPSG1ARE DC Input Power Supply Board

Technical Specifications

• Manufacturer: GE General Electric
• Series: Mark V
• Part Number: DS200TCPSG1ARE
• Functional Description: DC Input Power Supply Board
• Functional Acronym: TCPS
• PCB Coating: Normal Coating
• Functional Revision 1: A
• Functional Revision 2: R
• Artwork Revision: E

About the DS200TCPSG1ARE

The DS200TCPSG1ARE is a printed circuit board (PCB) originally manufactured by General Electric for use in the Mark V Turbine Control System Series. This PCB is used in the management and control systems of wind, steam, and gas turbine automated drive assemblies. Despite being part of an outdated product series, the Mark V Series is still highly sought after in the industrial marketplace due to its use of GE’s patented Speedtronic control system technology, first introduced with the Mark I Series in the mid to late 1960s. The DS200TCPSG1ARE is a revised version of the original DS200TCPSG1 DC Power Supply Input Board, featuring three significant product revisions.

Hardware Tips and Specifications

• Connectors: One 16-pin connector and one 9-pin connector
• Integrated Test Points: Several
• Replaceable Fuses: 3 (protect circuits on the board)
• Fuse Replacement Considerations: Fuses are secured with clamps that enable an electric current through the fuse. When excess current is introduced, the fuse element blows to stop the current and protect the board.
• Functional Product Number Details:
  • Series Tag: DS200 (indicates Mark V Series assembly version and domestic original manufacture location)
  • Functional Product Abbreviation: TCPS
  • Group: One Mark V Series product grouping
  • Primary Functional Revision: A-rated
  • Secondary Functional Revision: R-rated
  • Artwork Configuration Revision: E-rated
