GE Fanuc IC693MDL742 Sereis 90-30 DC Voltage Output Module

Description

The IC693MDL742 is an output module designed to interface with the Series 90-30 PLC, facilitating connections between the PLC and various external input devices such as sensors, switches, and push buttons.

Features

• Output Points:
  • Provides a total of 16 output points.
  • Organized into two separate banks, each containing eight points.
• Positive Logic Characteristics:Designed with positive logic, where the module sources current to the loads from the user common or positive power bus.
• Connection Details:The output device is connected between the negative power bus and the module output.

Specifications

• Power Types: Supports both AC and DC.
• Contact Point Modules: Available in configurations of 8, 16, and 32 points.
• Multiple Input Voltage Ranges: Allows flexibility in voltage compatibility.
• Inrush Current: 4.78 amps for 10 ms.
• Maximum Output Voltage Drop: 1 VDC.
• Off-state Leakage Current: 1 mA.
• ON Response Time: Maximum of 2 ms.
• OFF Response Time: Maximum of 2 ms.
• Power Consumption: Draws 130 mA (all outputs on) from the 5-volt bus on the backplane.
