GE Fanuc IC695CPU320 PACSystems RX3i CPU Module

Specifications

• CPU Performance:
  For detailed performance data, refer to Appendix A of the PACSystems CPU Reference Manual, GFK-2222V or later.

• Battery: Memory Retention:
  For battery selection, installation, and estimated life, refer to the PACSystems RX3i and RX7i Battery Manual, GFK-2741.

• Program Storage:

  • Up to 64 MB of battery-backed RAM
  • 64 MB of non-volatile flash user memory

• Power Requirements:

  • +3.3 VDC: 1.0 Amps nominal
  • +5 VDC: 1.2 Amps nominal

• Operating Temperature:
  0 to 60°C (32°F to 140°F)

• Floating Point Support:
  Yes

• Time of Day Clock Accuracy:
  Maximum drift of 2 seconds per day

• Elapsed Time Clock (Internal Timing) Accuracy:
  0.01% maximum

• Embedded Communications:

  • RS-232
  • RS-485

• Serial Protocols Supported:

  • Modbus RTU Slave
  • SNP
  • Serial I/O

• Backplane Support:
  Dual backplane bus support: RX3i PCI and high-speed serial bus

• PCI Compatibility:
  System designed to be electrically compliant with PCI 2.2 standard

• Program Blocks:

  • Up to 512 program blocks
  • Maximum size for a block: 128 KB

• Memory Configurations:

  • %I and %Q: 32Kbits for discrete
  • %AI and %AQ: Configurable up to 32K words
  • %W: Configurable up to the maximum available user RAM
  • Symbolic: Configurable up to 64 MB
