GE IC694MDL646 RX3i DC Voltage Input Module

Specifications

• Part Number: IC694MDL646
• Input Count, Type & Speed: 16 Points; Positive/Negative Logic; 1ms On/1ms Off
• Supply Voltage and On/Off Voltage: 24VDC; Range 20~30V; On >11.5V
• Backplane Current Consumption: 80mA @ 5VDC & 125mA @ 24VDC
• Approvals & Standards:
  • Ordinary Locations: UL 508, equivalent to CSA C22.2 No 142M1987 standard
  • Hazardous Locations: Class I, Div. 2, Groups A, B, C, D
• Mounting Format: On Panel/DIN Rail

Features

• High-speed and patented technology for faster throughput
• Hot swap capability
• A variety of voltage ranges, types, current capacities, isolation, and response times to meet diverse application needs
