MVI69E-MBTCP | ProSoft | Enhanced Communication Module

Description

The ProSoft MVI69-MCM is a Modbus Communication Module designed for use with Allen-Bradley CompactLogix and MicroLogix 1500 controllers. It enables seamless integration of Modbus devices into a Rockwell Automation system, facilitating efficient data exchange between Modbus RTU/ASCII devices and the CompactLogix or MicroLogix controllers.

Features

• Seamless Integration: Easily integrates Modbus RTU/ASCII devices with CompactLogix and MicroLogix controllers.
• High-Speed Communication: Supports high-speed communication, ensuring timely data exchange.
• User-Friendly Configuration: Provides an intuitive interface for easy configuration and setup.
• Robust Performance: Designed for reliable operation in industrial environments.
• Diagnostic Capabilities: Includes diagnostic features for monitoring and troubleshooting communication issues.

Technical Specifications

• Module Type: Communication module for Modbus RTU/ASCII
• Compatibility: Compatible with Allen-Bradley CompactLogix and MicroLogix 1500 controllers
• Communication Ports: Two serial ports, configurable for RS-232, RS-422, or RS-485
• Data Rates: Supports baud rates up to 115.2 kbps
• Protocol Support: Modbus RTU Master/Slave, Modbus ASCII Master/Slave
• Power Requirements: 24V DC, supplied from the CompactLogix or MicroLogix backplane
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Humidity: 5% to 95% non-condensing
