T8850 | ICS Triplex | Expander Interface Module

Description

• Purpose: Designed for reliable and accurate data acquisition in critical applications.
• Input Voltage: Operates with a 24 Vdc input voltage.
• Application: Suitable for process control systems, safety instrumented systems, and industrial automation.

Features

• Processing: High-speed processing capabilities.
• Redundancy: Provides redundant hardware and software for increased reliability.
• Fault Detection: Advanced fault detection and diagnostics capabilities.
• Protocols: Compatible with a range of communication protocols.
• Configuration: Offers flexible configuration options tailored to specific application needs.
• Output Channels: Provides 40 output channels per Fault Tolerant Adapter (FTA).
• Connections: Uses industry standard field device connections (2-wire).
• Mounting: Standard DIN rail compatibility for easy installation.
• Terminals: Features screw clamp terminals on both field and power sides.
• Operation: Operates at 24 Vdc with SmartSlot connection for hot replacement of output modules.
• Isolation: Divided into five isolated groups of eight channels each.
• Indication: On-board LED indication of field power supply status.
• Wire Size: Supports field terminal wire sizes from 12 AWG to 28 AWG.

Specifications

• Technology: Utilizes Trusted TMR (Triple Modular Redundant) technology.
• Input Type: Analog input.
• Signal Range: Accepts signals within a 0-10 Vdc range.
• Accuracy: Provides ±0.1% accuracy of full scale.
• Resolution: Offers 16-bit resolution for precise data acquisition.
