Yokogawa AIP830-111/EIM Operation Keyboard In Stock

Product View: AIP830 Flat Keyboard with USB Speaker

The AIP830 is a specialized flat keyboard designed for single-loop operation, featuring an integrated USB speaker. It is tailored for industrial environments where precise control and clear audio feedback are essential. The keyboard comes with several configuration options indicated by suffix codes, allowing users to customize the device according to their specific needs.

Specifications

General

• Model: AIP830
• Type: Flat keyboard with USB speaker
• Application: Single-loop operation
• Suffix Codes:
  • -1: Indicates the presence of a mode selection switch.
  • 1: Specifies the type B operation confirmation key.
  • 1: Always present, indicating a standard feature or configuration.
  • /EIM: Implies that the keyboard includes an English instruction manual.

Hardware

• PC Interface:
  • Interface Connector: USB A type x 2 (conforming to the USB standard)
• Functionality:
  • Operation Keyboard: Supports USB 2.0 full-speed bus-powered operation.
  • Sound Function: Also supports USB 1.1 full-speed bus-powered operation.
• Input Voltage: Requires 5 V±5% power supply, which is typically provided by the USB port of a PC.
• Maximum Consumption Current: 1 A.
• Weight:
  • Without VESA Bracket: 2.0 kg.
  • With VESA Bracket: 2.5 kg.
• Chassis Color: Black, matching the Munsell No. N1.5 color standard.
• Installation Category: IEC 61010-1 Class I, indicating that it is a device not directly connected to the main power supply

Features

• Integrated USB Speaker: Provides sound functionality via USB 1.1, enhancing user interaction through audible alerts or instructions.
• Dual USB Ports: Two USB A-type connectors allow for flexible connectivity and compatibility with various peripherals.
• Customizable Configuration: Users can select different suffix codes to tailor the keyboard's features, such as including a mode selection switch or specifying the type of operation confirmation key.
• Robust Design: Weighing between 2.0 kg and 2.5 kg depending on whether it includes a VESA bracket, this keyboard is sturdy enough for demanding environments.
• Color Standardization: The black chassis color adheres to the Munsell color system, ensuring uniformity in appearance.
• Safety Compliance: Classified under IEC 61010-1 for safety standards related to electrical equipment for measurement, control, and laboratory use.
